• Hani Sarah Mohamed Sabri Hospital Pengajar Universiti Putra Malaysia
  • Norafida Bahari
  • Syafeeq Md Nuh
  • Ahmad Sobri Muda




angiography, digital subtraction, clinical outcome, ischaemic stroke, modified Rankin scale



DSA (digital subtraction angiography) remains the gold standard in assessing the status of cerebral collaterals. Several studies have shown that the presence of good collateral circulation in ischemic stroke patients is associated with better functional outcomes with reduction of morbidity and mortality. Therefore, in this study, we aimed to assess the correlation between the collateral status seen on DSA cerebral angiogram with the clinical presentation of stroke and patients' functional outcomes.


We recruited a cohort of ischemic stroke patients who underwent DSA and collected demographic data, stroke risk factors and clinical data, which includes the National Institutes of Health Stroke Scale (NIHSS) scores, at time of admission. We assessed the collateral status and its grading using DSA and categorized based on established criteria. Subsequently we followed up the patients up at 3 months post stroke event to assess their functional outcomes using the modified Rankin Scale (mRS).


There was a significant association between good collateral status and favourable outcome in ischaemic stroke patients (p <0.05).

We also found that, there is correlation between the NIHSS (upon discharge) and neurological outcome (MRS at 90 day) with Spearman correlation coefficient of 0.849.


In conclusion, cerebral collateral status has the ability to prognosticate the functional outcome of ischemic stroke patients.


Bang OY, Park HY, Yoon JH, Yeo SH, Kim JW, Lee MA, Park MH, Lee PH, Joo IS, Huh K. Predicting the Long-Term Outcome after Subacute Stroke within the Middle Cerebral Artery Territory. Journal of Clinical Neurology. 2005;1(2):148-158. doi:10.3988/jcn.2005.1.2.148.

Iwasawa E, Ichijo M, Ishibashi S, Yokota T. Acute development of collateral circulation and therapeutic prospects in ischemic stroke. Neural Regeneration Research. 2016; doi:10.4103/1673-5374.179033.

Bang OY, Saver JL, Kim SJ, Kim GM, Chung CS, Ovbiagele B, Lee KH, Liebeskind DS. Collateral flow averts hemorrhagic transformation after endovascular therapy for acute ischemic stroke. Stroke. 2011;42:2235–2239.

Darwish ES, Othman MH, Youssef AH, et al. Predictive value of cerebral collaterals on CT angiography on the outcome of patients with acute anterior ischemic stroke receiving thrombolysis treatment. Egyptian Journal of Neurology, Psychiatry, and Neurosurgery. 2022;58:163. doi:10.1186/s41983-022-00599-y.

Mathan Raj, Shahizon Azura Mukari , Wan Asyraf Wan Zaidi , Ahmad Sobri Muda. Collateral Score on CT Angiography in patients with acute ischaemic stroke: A retrospective study. https://doi.org/10.32896/cvns.v1n1.1-7

Arteaga DF, Ulep R, Kumar KK, et al. Collateral status, hyperglycemia, and functional outcome after acute ischemic stroke. BMC Neurology. 2022;22:408. doi:10.1186/s12883-022-02943-4.

Tan BYQ, Wan-Yee K, Paliwal P, Gopinathan A, Nadarajah M, Ting E, Venketasubramanian N, Seet R, Chan BPL, Teoh HL, Rathakrishnan R, Sharma VK, Yeo LLL. Good Intracranial Collaterals Trump Poor ASPECTS (Alberta Stroke Program Early CT Score) for Intravenous Thrombolysis in Anterior Circulation Acute Ischemic Stroke. Stroke. 2016;47(8):2292-2298. doi:10.1161/STROKEAHA.116.013879.

Banks JL, Marotta CA. Outcomes validity and reliability of the modified Rankin Scale: Implications for stroke clinical trials. A literature review and synthesis. Stroke. 2007;38:1091-1096. doi:10.1161/01.STR.0000258355.23810.c6.

Luo G, Mo D, Tong X, Liebeskind DS, Song L, Ma N, Gao F, Sun X, Zhang X, Wang B, Jia B, Fernandez-Escobar A, Miao Z. Factors Associated with 90-Day Outcomes of Patients with Acute Posterior Circulation Stroke Treated By Mechanical Thrombectomy. World Neurosurgery. 2018; doi:10.1016/j.wneu.2017.09.171. Epub 2017 Oct 5.

Mistry EA, Yeatts S, de Havenon A, Mehta T, Arora N, De Los Rios La Rosa F, Starosciak AK, Siegler III JE, Mistry AM, Yaghi S, Khatri P. Predicting 90-Day Outcome After Thrombectomy: Baseline-Adjusted 24-Hour NIHSS Is More Powerful Than NIHSS Score Change. Stroke. 2021;52(8):2547-2553. doi:10.1161/STROKEAHA.120.032487.

Alves HCBR, Pacheco FT, Rocha AJ. Collateral blood vessels in acute ischemic stroke: A physiological window to predict future outcomes. Arquivos de Neuro-Psiquiatria. 2016;74(5):404-410. doi:10.1590/0004-282X20160050

Elessawi D, Nasf A, Shalash A, El Husseiny D, Bakry E. Assessment of cerebral collaterals in acute ischemic stroke by CT cerebral angiography and its relation to the functional outcome. Egyptian Journal of Radiology and Nuclear Medicine. 2019;32(2):155-167.

Faber JE, Chilian WM, Deindl E, van Royen N, Simons M. A brief etymology of the collateral circulation. Arteriosclerosis, Thrombosis, and Vascular Biology. 2014;34:1854-1859.

Hwang J, Lee MJ, Chung JW, Bang OY, Kim GM, Chung CS, Lee KH. NIHSS sub-item scores predict collateral flow in acute middle cerebral artery infarction. Interventional Neuroradiology. 2018; doi:10.1177/1591019918788056.

Wufuer A, Wubuli A, Mijiti P, Zhou J, Tuerxun S, Cai J, Zhang X. Impact of collateral circulation status on favorable outcomes in thrombolysis treatment: A systematic review and meta-analysis. Exp Ther Med. 2020;15:707–718.



How to Cite

Mohamed Sabri, H. S., Norafida Bahari, Syafeeq Md Nuh, & Ahmad Sobri Muda. (2024). EFFECTS OF CEREBRAL COLLATERAL (DSA CEREBRAL ANGIOGRAM) ON CLINICAL PRESENTATION AND NEUROLOGICAL IMPROVEMENT IN ISCHAEMIC STROKE. Journal Of Cardiovascular, Neurovascular & Stroke, 6(2), 1–11. https://doi.org/10.32896/cvns.v6n2.1-11
